Input Voltage AC: 100-240 VAC Nominal, Auto-switching, 47-63 Hz
AC Maximum Input Current 2.5A
AC Input Voltage Range (nominal) 100-127VAC and 200-240VAC
Output +12V/10A
Max Power Consumption 150 watts
UX power supplies are tested and certified to meet UL / cUL / IEC 60950-1 safety requirements.
For more information about the UX power supply units, see .UX1000 Power Supplies
Networking Interfaces
The UX1000 base configuration includes 2 Ethernet ports on the front panel of the unit, or 4 Ethernet ports if the ASM is installed.
4 X 10/100/1000 Base-T ports (max).
UX1000 Power Supplies
This page describes the UX1000-XXXXXX Power Supply unit installed in the UX1000 chassis.
For information on power connection requirements for the UX system, see .Power Connection Requirements
Replace the UX1000 power supply units with NET-provided units only.
Specifications
Specifications
The UX system comes equipped with a single power supply which complies with the following specifications:
Item Specification
Input Voltage AC: 100-240 VAC Nominal, Auto-switching, 47-63 Hz
AC Maximum Input Current 2.5A
AC Input Voltage Range (nominal) 100-127VAC and 200-240VAC
Output +12V/10A
Max Power Consumption 150 watts
UX power supplies are tested and certified to meet UL / cUL / IEC 60950-1 safety requirements.
UX2000 Hardware Specifications
This section describes the dimensional, environmental, power, and network specifications and requirements for the UX2000 System.
Dimensions and Weight
Environmental Ranges (Operation and Storage)
Power Supply
Networking Interfaces
Dimensions and Weight
Equipment Height mm/in. Width mm/in. Depth mm/in. Weight lb./kg
Chassis with no interface cards or expansion modules (1RU) - 44 mm / 1.75 in. 444 mm / 17.5 in. 534 mm / 21 in. 16.5 lbs / 7.48 kgs
