Maximum supported configuration (1RU) - 44 mm / 1.75 in. 444 mm / 17.5 in. 534 mm / 21 in. 23 lbs / 10.43 kgs
Environmental Ranges (Operation and Storage)
Environmental Parameter Specification
Operating Environmental Conditions Temperature: 5º to 40º Celsius
Humidity: 5% to 85% RH non-condensing
Altitude: 60 meters below sea level to 1800 meters above sea level
Storage Environmental Condition Temperature: -40º to 70º Celsius
Cooling System Internal forced convection
Power Supply
The UX system comes equipped with either a single power supply, or dual redundant power supplies which comply with the following specifications:
Item Specification
Input Voltage AC: 100-240 VAC Nominal, Auto-switching, 47-63 Hz
AC Maximum Input Current 5A at 115VAC and 2.5A at 230VAC
AC Input Voltage Range (nominal) 100-127VAC and 200-240VAC
Output 300 W-AC: +5V/20A, +12V/24A, -12V/0.6A, +3.3V/20A, +5VSB/3A
Max Power Consumption 300 watts
UX power supplies are tested and certified to meet UL / cUL / IEC 60950-1 safety requirements.
For more information about the UX power supply units, see .UX2000 Power Supplies
Networking Interfaces
The UX2000 base configuration includes 5 Ethernet ports on the front panel of the unit.
1 x 10/100/1000 Base-T administration port (used for initial setup)
4 x 10/100/1000 Base-T ports
UX2000 Power Supplies
This page describes the UX2000-PSU-AC Power Supply units installed in the UX2000 chassis. The UX2000 chassis is equipped with dual power supply
bays, supporting fully redundant power connections.
For information on power connection requirements for the UX system, see .Power Connection Requirements
Specifications
LED Status Indicator
Specifications
The UX system comes equipped with either a single power supply, or dual redundant power supplies which comply with the following specifications:
Item Specification
Input Voltage AC: 100-240 VAC Nominal, Auto-switching, 47-63 Hz
AC Maximum Input Current 5A at 115VAC and 2.5A at 230VAC
