AC Input Voltage Range (nominal) 100-127VAC and 200-240VAC
Output 300 W-AC: +5V/20A, +12V/24A, -12V/0.6A, +3.3V/20A, +5VSB/3A
Max Power Consumption 300 watts
UX power supplies are tested and certified to meet UL / cUL / IEC 60950-1 safety requirements.
LED Status Indicator
The UX power supplies include a LED status indicator on the back of the unit. The following table explains the meaning of the various LED Status states.
LED Status Power Supply Status Description
Solid Green Normal (AC on, DC power on)
Blinking Green Standby (AC on, DC standby on, DC power off) power to the UX main board is off
Solid Red Alarm Condition
Blinking Red Fan Failure
Off AC Failure
UX2000 Interface Cards
The UX system allows for the use of interface cards – sometimes referred to as a line card or carrier card – for connecting to specific call equipment or
carrier lines. This section describes the available interface cards for the UX system.
Inserting and Removing Interface Cards
T1-E1 PSTN Interface Cards
Inserting and Removing Interface Cards
This section describes the steps for inserting and removing from the rear of the UX chassis.Interface Cards
Removing an Interface Card
Inserting an Interface Card
Removing an Interface Card
To Remove an Interface Card
Loosen the screws on the right and left side of the interface card until they spin freely.
Depress the red buttons on the inside of the attachment levers until they click and lock into place. The Hot Swap status LED should now be lit.
Do not remove the Interface Card while Hot Swap LED is ON. When the Hot Swap LED is on, UX is in the process of shutting
down system resources associated with the interface card.
Wait until the Hot Swap LED turns off. When the LED turns off, it is safe to remove the card from the chassis.
Grip the inside of the attachment levers and push toward the outside edges of the card.
Carefully pull the card free of the chassis.
