Network Equipment Technologies SBC 2000 - Page 25

1.
2.
3.
Inserting an Interface Card
You must power down the UX system before installing or removing Interface Cards. Hot swapping of Interface Cards is not supported in
UX 1.2.
To Insert an Interface Card
Carefully insert the card so that the left and right edges slide into the mounting slots.
Grip the outside of the attachment levers and push toward the inside of the card until the card locks into place.
The red buttons click and pop out when the card is properly locked into place.
Tighten the screws on the right and left side of the interface card.
