Requirements
Minimum Wire Size 14 AWG
Minimum Voltage Rating 300 V
Insulation PVC
Conductor Stranded
Europe
Requirements
Minimum Wire Size 1.63 mm
Minimum Voltage Rating 300 V
Insulation PVC
Conductor Stranded
For more information on UX power requirements, see .Power Connection Requirements
Grounding Connections
UX Series equipment must be grounded to the building ground network. For ground wire specifics, see the tables below for the United States, Canada
and Europe.
Only qualified service personnel should perform the electrical procedures for grounding wire installation.
United States and Canada Grounding Connections
Requirements
Minimum Wire Size 14 AWG
Minimum Voltage Rating 300 V
Conductor Stranded
Europe Grounding Connections
Requirements
Minimum Wire Size 1.63 mm
Minimum Voltage Rating 300 V
Conductor Stranded
For more information on UX grounding requirements, see .System Grounding Requirements
