NETZSCH NM038BY - Page 87

SPARE PARTS LIST
2018-02-21 Page 1
1 2 3 4
Part
Pos. Quant.
Unit Designation
Size/Dimension Norm Material/Surface
Ident-No
0085 1 ST lantern
NM038B-
0120 4 ST spring washer
DIN127
0125 4 ST hex head screw
DIN933
0140 4 ST hex nut
DIN934
1030 1 ST pin
1035 1 ST ring
NM038B
1050 1 ST connecting shaft
NM038B
1998 1 ST coupling rod
NM038--
1999 1 ST rotor
NM038--
2005 1 ST end connection
NM038--
2010 1 ST pump housing
NM038-Y
2015 1 ST drain plug
DIN910
2016 1 ST drain plug
DIN910
2020 4 ST stud screw
DIN938
2025 4 ST spring washer
DIN127
2030 4 ST hex nut
DIN934
2035 1 ST support foot
NM038-1
3005 1 ST stator
NM038--
3010 4 ST stator bolt
NM038-0
3015 4 ST spring washer
DIN127
3020 6 ST hex nut
DIN934
3070 4 ST disk / washer
DIN125
Model
Commission-Nr. Product: NEMO® Aggregat NPS
4300003998/000100 Type: NM038BY AGNM02 00
NM038BY - D8411276 - 4300003998 - 000100 - NPS 00229929
87
