User Manual
1.5 Packing List
2-3/8” or 2-3/4” （1pc）
Square spindle ( 1pc)
Part #5. Rubber gasket (2pcs)
Part #9. Manual & template (1pc)
-4-
Part #2. Adjustable single latch
Bag A Includes:
Strike (1pc)
Strike plate (1pc)
1.2” Screw
for strike plate (2pc)
Bag B Includes:
1.2” Screw
for Adjustable latch (2pc)
(2 Extra 1.2” screws included for
replacement)
Bag C Includes:
Long Connector Screw (3pc)
(for use if your door
width is 1.6 - 2 inches)
Bag D Includes:
Mechanical Keys (3pc)
Alan Wrench (1pc)
Part #7. IR Remote (1pc)
Loose Parts:
Part #1. Short connector screw
( 3 pcs)
Part #3. Front Panel（1pc）
Part #4. Back Panel（1pc）
Part #6. Iron fixing board (1pc)
Iron fixing board screw (2pc)
Part #8. Batter cover screw
(1pc)
To Next Page
