Spare Parts:
ITEM # IMAGE DESCRIPTION UM
Miscellaneous Components - Continued
500350
Grommet, Probe Bushing 5/16” 1 EA.
500351
Bushing, Probe Insulator 1 EA.
500382
NA
Probe Assembly Kit, 1.537”
[Consists of: 1 ea. 500350, Probe Assy., & Instruction]
1 EA.
781539
Screw, 8-32 X 1 3/8” PPHMS SS
[Used on Fan Assembly]
1 EA.
103600
Fan Assembly 1 EA.
123092
Fan Harness, With Rectifier & Capacitor 1 EA.
100669
Bridge Rectifier 1 EA.
131133
Grommet, Solenoid Valve [Dump] 1 EA.
