Newco LCD-2 - Product Ratio and Blend Configuration

13-May-13 Phone: 1.800.325.7867 Fax: 1.636.925.0029 www.newcocoffee.com
7
Program selection single product:
To program a selector switch to create a drink using the product on the right, enter the pump speed
from Chart A in to Pump 2 and set the speed of Pump 1 to 0:00.
Program selection blend products:
To program a selector switch to create a blend using both products, set the speeds of Pump 1 and Pump 2 using Chart B
as a guideline.
High Flow Rate Ratio Chart (Use this chart if the unit is a high flow unit.) See
page 8 for visual of the nozzle.
Ratio
Chart A
Pump Speed
Setting
Single
Chart B
Pump Speed
Settings
(Blend 50/50)
Chart C
Pump Speed
Settings
(Blend 25/75)
45:1 9 4/4 1/6
40:1 11 5/5 1/8
35:1 13 6/6 1/10
30:1 15 7/7 2/11
25:1 19 8/8 3/13
20:1 - 11/11 -
15:1 - 17/17 -
14:1 - 18/18 -
Low Flow Rate Chart (Use this chart if the unit is a low flow unit.) See page 8 for
visual of the nozzle.
Ratios
Chart A Pump Speed
Setting
Chart B Pump Speed
Settings
(Single) (Blend)
45:1 5 1/1
40:1 6 2/2
35:1 7 2/2
30:1 9 3/3
25:1 11 4/4
20:1 15 6/6
15:1 24 9/9
