2 Technical Data
Specification
Rated Input Power(static) 1300W
Comparable Petrol Outboard 3 HP
Battery Type
• Deep cycle marine battery
• LFP lithium battery
• Lithium cobalt oxide battery
Battery Input voltage
• 36V-Deep cycle marine battery
• 36V-LFP Lithium battery
• 36V-Lithium cobalt oxide battery
Max. Overall Efciency 50%
Rated Rotation Speed 1500 rpm
Total Weight
• Short: 23.8 lbs (10.8kg)
• Long: 24.3 lbs (11kg)
Shaft Length
• Short: 25 in. (635 mm)
• Long: 30 in. (760mm)
Control System Digital control with integrated tiller
Tilt Angle Manual, 80°
Trim Angle Manual, 0°, 7°, 14°, 21°
Propeller Diameter 10.6 in. (270 mm)
