PARTS LIST
26
J19Y06P-1
REF# DESCRIPTION QTY REF# DESCRIPTION QTY
1 Main Lid 1 27 Utility Drawer Slide, Right 1
2 Main Lid Screw 2 28 Side Shelf, Left B 1
3 Main Lid Screw Cover 2 29 Side Shelf, Left A 1
4 Logo 1 30 Side Shelf Trim Panel,Left 1
5
Main Lid Handle Heat Insulating
Spacer
2 31 Side Panel, Left 1
6 Temperature Gauge 1 32 Front Trim Panel, Left 1
7 Main Lid Handle 1 33 Swivel Caster with Brake 2
8 Grease Slide Panel, Top 1 34 Cart Frame , Front 1
9 Main Burner Bowl Assembly 1 35 Door Hinge 4
10 Rotisserie Motor 1 36 Front Door, Left 1
11 Rotisserie Motor Bracket 1 37 Front Door, Right 1
12 Front Baffle 1 38 Door Magnet 4
13 Pulse Igniter Module Cover 1 39 Door Magnet Bracket 1
14 Pulse Igniter Module 1 40 Swivel Caster 2
15 Sear Gas Valve 1 41 Bottom Panel, LP 1
16 Side Burner Hose 1 42 Tank Bolt 1
17 Rotisserie Gas Valve 1 43 Door Handle Plastic Insert 1
18 Main Gas Valve 3 44 Lighting Rod 1
19 Main Manifold 1 45 Front Trim Panel, Right 1
20 Main Control Panel 1 46 Side Panel, Right 1
21 Bezel 6 47 Gas Valve Clamp 6
22 Control Knob 6 48 Side Manifold 1
23 Utility Drawer Slide Bracket 2 49 Side Burner Gas Valve 1
24 Utility Drawer Slide, Left 1 50 Side Burner Flex Gas 1
25 Utility Drawer 1 51 Side Burner Orifice Brass Connector 1
26 Door and Utility Drawer Handle 3 52 Side Burner Pipe
