KEY# DESCRIPTION QUANTITY KEY# DESCRIPTION QUANTITY
01 Main Lid 1 37 Side Shelf Control Panel, Right 1
02 Main Lid Screw 2 38 Side Burner Assembly 1
03 Burner Pin Assembly 4 39 Side Burner Igniter Wire 1
04 Temperature Gauge 1 40 Searing Burner Lid 1
05 Temperature Gauge Housing 1 41 Searing Burner Lid Hinge Rod, Left 2
06 Logo 1 42 Searing Burner 1
07 Hood Buffer A 2 43 Searing Burner Cooking Grate 1
08 Control Knob 6 44 Searing Burner Igniter Wire 1
09 Bezel 4 45 Searing Burner Bowl Assembly 1
10 Main Control Panel 1 46 Searing Burner Grease Tray 1
11 Searing Burner Manifold 1 47 Searing Burner Gas Valve 1
12 Side Burner Flex Gas Line 2 48 Side Shelf Control Panel, Left 1
13 Main Manifold 1 49 Bottom Panel, LP 1
14 Side Burner Manifold 1 50 Front trim panel, Rear 1
15 Regulator, LP 1 51 Back Panel 1
16 Main Burner Gas Valve 4 52 Side Panel, Left 1
17 Front baffle 1 53 Swivel Caster 1
18 Main burner bowl assembly
Non-
replaceable
54 Swivel Caster with Brake 1
19 Hood Buffer B 2 55 Caster 2
20 Main Burner 4 56 Door iron piece 1
21 Main Burner Igniter Wire A 1 57 Triangle Bracket, Left 1
22 Main Burner Igniter Wire B 1 58 Triangle Bracket, Right 1
23 Main Burner Igniter Wire C 1 59 Side Panel, Right 1
24 Main Burner Igniter Wire D 1 60 Cart Frame, Front 1
25 Heat Diffuser 4 61 Door Magnet 2
26 Cooking Grid with Hole 2 62 Front Door, Right 1
27 Warming Rack 1 63 Front Door, Left 1
28 Grease Box 1 64 Lighting Rod 1
29 Grease Tray 1 65 Door Handle Seat 4
30 Side Burner Lid, Right 1 66 Door Handle Tube 2
31 Side Burner Lid Hinge Rod, Right 2 67 Tank Tray Bracket A 1
32 Side burner lid hinge rod pin 4 68 Tank Tray Slide Block Plate 1
33 Side Burner Cooking Grate, Right 1 69 Tank Tray Slide 2
34 Side Burner Bowl Assembly, Right 1 70 Tank Tray 1
35 Side Burner Gas Valve, Right 1 71 Tank Tray Bolt 1
36 Pulse Igniter Module 1 72 Tank Tray Bracket B 1
Parts List
9
rts
Important: Use only parts listed above. When ordering
parts, providing the following information:
• Model #
• Serial # (found on the door inner of your grill)
• Part Number (see PART# in chart)
• Part Description
• Quantity of parts needed
If you are missing hardware or have damaged pa
after unpacking grill, call 1-800-913-8999
for replacements.
To order replacement parts after using grill, call:
1-800-913-8999.
