GEO M12 HARDWARE SETUP PROCEDURE Page 53/90
Disassembly
- While holding GEO M12 to be dismounted, pull AutoRigTM on both sides and hold the side knob
(AutoRigTM remains in the open position).
- Remove the rear quick release pin BL820
- Unlock the GEO M12 link bar by pulling the latch.
- Remove GEO M12
