Nexo P10

MAINTENANCE
P10 Page 13 / 18
MAINTENANCE
NOTE:
Speakers and Grills can be sent back to NEXO for recycling
Driver access
1
P10 Unlock the 2 quarter-turn screws, Remove the grille.
(P10-TIS see above)
2
Remove 4 screws.
Tightening torque: 3.5 Nm (Thread Locker: Loctite 242)
3
Remove the horn.
4
To access to the HF diaphragm, remove 4 screws.
Tightening Torque: 2 Nm
