Nexo P10

TECHNICAL SPECIFICATIONS
P10 Page 15 / 18
TECHNICAL SPECIFICATIONS
P10 WITH NEXO ELECTRONICS
Model
P10
Frequency range (±6dB)
63 Hz  20 kHz
Peak SPL Level (1m)
136dB Peak
Operating voltage
50Vrms (150Vpeak)
HF dispersion
(according to horns)
100°x100° (Default) - 110°x60° (Optional)
Crossover Frequency
63Hz  85Hz  120Hz
Nominal Impedance

SPECIFICATIONS
Model
P10
Components
1 x Coaxial Neodymium LF 10-  long excursion & HF 1.7- 
Material
Custom made bent plywood of Baltic birch and poplar
Finish
Black or white structural paint
Front finish
P10: Magnelis® steel front grille + Back mesh
P10-TIS: Black or white acoustic fabric fitted front Magnelis® front grille
Fittings
Handle on both sides
Threated inserts on the back and on both sides for connection of mounting
accessories
Stand fitting on both sides 
Connector
4x NL4, 4 poles connectors; 2 at the back and one on each side
Weight
15 kg / 33 lb
Dimensions












