HF DIRECTIVITY
P10 Page 9 / 18
HF DIRECTIVITY
→ The P10 speaker can be used in horizontal or vertical position.
→ The standard horn is a 100° - 10ersion by changing the horn. Different
mounting possibilities and horn rotation allow to deal with every request.
1
P10 Unlock the 2 quarter-turn screws, Remove the
grille.
2
P10-TIS Loosen the 2 screws. Remove the grille.
3
Remove the horn to place the PNT-P10FLG11060.
4
If it necessary, rotate it.
5
Magnets keep the horn in place.
6
Replacing the grille.
When replacing the grille, ensure it is well positioned in the top
blade.
CROSSOVER FREQUENCY
→ 63 Hz: Full range application.
→ 85 Hz: Use as « front fill » on stage, complementing a main system. Use with a NEXO subwoofer, e.g. L15.
→ 120 Hz: Long throw application.
