MAINTENANCE
P12 Page 13 / 18
MAINTENANCE
Driver access
1
Unlock the 2 quarter-turn screws, Remove the grille.
2
Remove 8 screws.
3
Remove the stickers.
4
Remove the 2 screws.
5
Remove the horn.
6
To access to the HF diaphragm, remove 4 screws.
