Nexo P12 User Manual

HF DIRECTIVITY
P12 Page 9 / 18
HF DIRECTIVITY
 The P12 speaker can be used in horizontal or vertical position.
 The standard horn is a 60° - 60° HF dispersion. It’s easy to change the HF dispersion by adding a specific flange. Different
mounting possibilities and flange rotation allow to deal with every request.
1
Unlock the 2 quarter-turn screws, Remove the grille.
2
Remove the 4 HF Cap and store them.
3
Place the flange, if necessary rotate it.
4
Magnets keep the flange in place.
When replacing the grille, ensure it is well positioned in the top blade before fasten with quarter-turn screws.
CROSSOVER FREQUENCY
 60 Hz: Full range application.
 85 Hz: Use as « front fill » on stage, complementing a main system. Use with a NEXO subwoofer, e.g. L15.
