Nexo P12

TECHNICAL SPECIFICATIONS
Page 16 / 18 P12
TECHNICAL SPECIFICATIONS
P12 WITH NEXO ELECTRONICS
Model
P12
Frequency range (±6dB)
60 Hz – 20 kHz
Peak SPL Level (1m)
138dB Peak (Passive mode) / 140dB Peak (Active mode)
Operating voltage
55Vrms (180Vpeak)
HF dispersion
(according to horns)
60°x60° - 90°x40° - Asymmetrical Dispersion 60° to 100°x40°
Crossover Frequency
60Hz – 85 Hz
Nominal Impedance
Active mode (8Ω LF, 8Ω HF) – Passive mode: 8Ω
SPECIFICATIONS
Model
P12
Components
LF: 1x12” - 8Ω; HF : 1x 3 ‘’ - 8Ω - Neodymium driver
Material
Baltic birch / Poplar plywood
Finish
Black or white structural paint
Front finish
Steel front grille + Back mesh
Fittings
Handle on both sides
Threated inserts on the back and on both sides for connection of mounting
accessories
Stand fitting on both sides (35mm / 1”3/8)
Connector
4x NL4, 4 poles connectors; 2 on the back and 1 on both sides
Weight
20 kg / 44 lb
Dimensions
