PRESET
P12 Page 7 / 18
PRESET
Please consult nexo-sa.com for NEXO TD Controllers firmware information.
For the P12, the following setups are available:
 MAIN is the recommended setup for most FOH application, similar to previous firmware setup.
 MONITOR is recommended for monitor applications. Warning: this setup is a low latency setup and therefore its phase is not
compatible with other NEXO cabinets, including subs.
Passive Mode
• P12 MON PA 6060, with high-pass at 60 or 85 Hz.
• P12 MON PA 9040, with high-pass at 60 or 85 Hz.
• P12 MON PA PSguide, with high-pass at 60 or 85 Hz
• P12 MAIN PA 6060, with high-pass at 60 or 85 Hz.
• P12 MAIN PA 9040, with high-pass at 60 or 85 Hz.
• P12 MAIN PA PSguide, with high-pass at 60 or 85 Hz.
Active Mode
WARNING: Do not mix directivity and/or modes
P12 MON HF 6060 with P12 MON LF 6060 =====> OK
P12 MAIN HF 6060 with P12 MON LF 6060 =====> NOT OK
P12 MON HF 9040 with P12 MON LF 6060 =====> NOT OK
• P12 MON HF 6060, with high-pass at 60 or 85 Hz.
• P12 MON HF 9040, with high-pass at 60 or 85 Hz.
• P12 MON HF PSguide, with high-pass at 60 or 85 Hz.
• P12 MON LF 6060, with high-pass at 60 or 85 Hz.
• P12 MON LF 9040, with high-pass at 60 or 85 Hz.
• P12 MON LF PSguide, with high-pass at 60 or 85 Hz.
• P12 MAIN HF 6060, with high-pass at 60 or 85 Hz.
• P12 MAIN HF 9040, with high-pass at 60 or 85 Hz.
• P12 MAIN HF PSguide, with high-pass at 60 or 85 Hz.
• P12 MAIN LF 6060, with high-pass at 60 or 85 Hz.
• P12 MAIN LF 9040, with high-pass at 60 or 85 Hz.
• P12 MAIN LF PSguide, with high-pass at 60 or 85 Hz.
P12
Front of house and stage monitor applications
