2.4 Connection of the AC adapter to the electric system
Plug the 3-pin cannon connector of the AC adapter completly in the power
input
Use the “push” safety hook to disconnect it and extract it gently.
ATTENTION: do not use AC adapter different from the one supplied, it
could cause serious damages at the internal circuitation.
Do not connect the 3-pin cannon connector in other appliances, it has
been studied to be used only in this controller.
2
MAKE SURE THAT VOLTAGE AND POWER FREQUENCY CORRESPOND
TO WHAT IS REPORTED ON THE AC ADAPTER PLATE.
The supplied AC adapter has a plug, therefore you should only plug it in the
socket.
Press
Power key
to verify the correct installation.
If pressing the
Power key
no one led light up, please check if there is ten-
sion in the electric socket or check the connection between AC adapter-
controller and AC adapter-electric socket.
If the problem persist, please consult your dealer.
2.3 Input connection for power supply
GB
1
