16
The above diagram is for illustration purposes only.
Gently rotate the front bezel to adjust
the filter. Rotate the filter until the windscreen
reflection can no longer be seen on the Dash
Cam display (see below).
Once the reflection can no longer be seen,
operate the Dash Cam normally. Please note; it
may not be possible to fully remove the reflection,
but using the Polarising Filter will noticeably
improve your video quality.
Adjust the Polarising Filter
The most effective way to set up your Polarising Filter (1) is to place a piece of plain white paper (2) on
your dashboard (3) under the rear view mirror. With your camera turned ON you will see the reflection (4)
of the paper in the LCD screen of the Dash Cam. Look at the reflection (4) on the windscreen through the
Dash Cam display (5).
4
2
3
Polarising Filter
The Polarising Filter (highlighted on the Dash Cam, below) is designed to reduced the glare on
your windscreen as seen through the Dash Cam, allowing you to record the road ahead clearly.
In bright sunlight the filter will also enhance the colour and contrast levels to help capture number
plates and other vital details.
Do not place fingers on the glass lens of the filter.
Do not adjust the filter while in control of the vehicle
5
1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NextBase 322GW and is the answer not in the manual?

NextBase 322GW Specifications

General IconGeneral
Night visionYes
Product colorBlack, Silver
Country of originChina
Languages supportDEU, DUT, ENG, ESP, FRE, ITA, NOR
Number of cameras1
Maximum frame rate60 fps
Power cable length4 m
Collision detectionNo
Aperture range (F-F)1.6 - 1.6
Main camera resolution1920 x 1080 pixels
Main camera viewing angle140 °
Video compression formatsMP4
Main camera sensor resolution2.12 MP
Battery life15 min
Battery weight6 g
Output current2 A
Output voltage3.7 V
Battery capacity320 mAh
Operating voltage12 V
Power source typeBattery, Cigar lighter
Input operation voltage (max)24 V
Storage temperature (T-T)-20 - 45 °C
Display diagonal2.5 \
Display resolution (numeric)311 pixels
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size128 GB
Quantity per pack7 pc(s)
Accessories includedVdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Package typeBox
Package width85 mm
Package height45 mm
Package weight410 g
Quantity per pallet720 pc(s)
Master (outer) case width280 mm
Master (outer) case height370 mm
Master (outer) case length330 mm
Master (outer) case weight1025 g
Customs product code (TARIC)8525890000
Master (outer) case GTIN (EAN/UPC)5060384255675
Export Control Classification Number (ECCN)EAR99
Number of shipping (inner) cases per master (outer) case20 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth47 mm
Width82 mm
Height46 mm
Weight82 g
