NextBase 322GW User Manual

17
First Time Use
To ensure the set up of this Dash Cam is as quick and simple as possible, there is an easy to follow
‘First Time Use’ menu.
This menu is used to set your preferred Language, Country (inc. Time Zone) and Speed Units.
This menu will appear when:
1. The Dash Cam is first turned on.
2. There has been a Firmware Update applied to the Dash Cam and ‘Keep User Settings’ has been
set to OFF. If It is set to ON, your Dash Cam will start normally, with your settings intact.
3. After the Dash Cam’s settings have been reset, by using the ‘Default Settings’ option in
the Setup Menu.
Follow the on-screen instruction to select the Language, Country, and Speed Units.
The settings that influence the displayed time & date will be applied upon receiving a GPS connection.
The First Time Use menu is in place to get you up and running quickly and smoothly.Note:
The settings you choose during First Time Use can be changed at any later time in the setup menus.
See next page for the First Time Use screens.
Before you can use your Dash Cam, it is essential to make sure it is fully charged. Connect your Dash Cam
via the USB port to a home power source such as a PC or home USB socket for approximately 2 hours.

NextBase 322GW Specifications

General

Night vision	Yes
Product color	Black, Silver
Country of origin	China
Languages support	DEU, DUT, ENG, ESP, FRE, ITA, NOR
Number of cameras	1
Maximum frame rate	60 fps
Power cable length	4 m
Collision detection	No
Aperture range (F-F)	1.6 - 1.6
Main camera resolution	1920 x 1080 pixels
Main camera viewing angle	140 °
Video compression formats	MP4
Main camera sensor resolution	2.12 MP
Battery life	15 min
Battery weight	6 g
Output current	2 A
Output voltage	3.7 V
Battery capacity	320 mAh
Operating voltage	12 V
Power source type	Battery, Cigar lighter
Input operation voltage (max)	24 V
Storage temperature (T-T)	-20 - 45 °C
Display diagonal	2.5 \
Display resolution (numeric)	311 pixels
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Quantity per pack	7 pc(s)
Accessories included	Vdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Package type	Box
Package width	85 mm
Package height	45 mm
Package weight	410 g
Quantity per pallet	720 pc(s)
Master (outer) case width	280 mm
Master (outer) case height	370 mm
Master (outer) case length	330 mm
Master (outer) case weight	1025 g
Customs product code (TARIC)	8525890000
Master (outer) case GTIN (EAN/UPC)	5060384255675
Export Control Classification Number (ECCN)	EAR99
Number of shipping (inner) cases per master (outer) case	20 pc(s)

Weight and Dimensions

Depth	47 mm
Width	82 mm
Height	46 mm
Weight	82 g
