NextBase 322GW User Manual

19
Resolution
Change your Dash Cam’s recording resolution
Options: 1440P @ 30FPS (frames per second), 1080P @ 60FPS, 1080P @ 30FPS
Default: 1440P @ 30FPS
The resolution of an attached Rear Facing Camera is dictated by the chosen resolution of the
Front Facing camera. The resolution of the Rear Camera cannot be altered independently of the
resolution of the Front Camera; the two resolutions are linked together to ensure maximum
performance. See the table below for the Rear Camera resolutions:
Exposure
Adjust the exposure level for different lighting conditions.
Options: Values range from -6 to +6
Default: 0
Video Length
Set the length of the individual recorded video files. The Dash Cam will continue recording, filling
the memory card. When the memory card becomes full, the oldest file will be automatically
deleted to make space for the new recording.
Old Protected Files can be overwritten; back up important files as soon as possible to avoidNote:
losing your footage. See page 6 for more details.
Options: 1 minute, 2 minutes, 3 minutes
Default: 1 minute
Audio
Turn On/Off the microphone for video recording.
Options: On and Off
Default: On
Time Stamp
Turn On/Off the time and date stamp shown on recorded files.
Options: On and Off
Default: On
Menus
Press the ‘Menu’ button (top left of the Dash Cam display) to enter the Dash Cam’s menu system.
1
2
3
4
Video Settings:
- Resolution
- Exposure
- Video Length
- Audio
- Time Stamp
- Speed Stamp
- GPS Stamp
- Model Stamp
- Dual Files
- Time lapse
- Number Plate
- G Sensor
Setup:
- Screen Saver
- Alerts
- Recording History
- Parking Mode
- Language
- Country
- Time Zone / DST
- Time & Date
- Speed Units
- Device Sounds
- Screen Dimming
- Auto Power Off
- Keep User Settings
- System Info
- Format SD Card
- Default Settings
Driver Assistance:
- Emergency SOS
- Reversing Camera
Connected Apps:
- MyNextbase
- Alexa
Resolution
Front Camera
Rear Camera (if connected)
1440P @ 30FPS
1080P @ 30FPS
1080P @ 60FPS
720P @ 30FPS
1080P @ 30FPS
720P @ 30FPS
Connect Apps
Video Settings
The default settings have been carefully selected to allow you to use your Dash Cam
without the need to change any settings. However, should you wish to change a setting then
please see below:
- Use the touch screen to select a settings submenu
(Video Settings, Setup, Driver Assistance, Connect Apps)
- Once in the submenu, use the touchscreen to select which function to change.
- When swiping through the menu pages, swipe from the middle of the screen, to avoid accidentally
selecting a submenu/function.
Notes:
- Menus are not accessible whilst the Dash Cam is recording.
- Within the Setup Menu there is a ‘Default Settings’ option to allow you to reset the Dash Cam
to the factory defaults, if required.
Menu Tree:
See below for the settings to be found under each submenu:
5

NextBase 322GW Specifications

General

Night vision	Yes
Product color	Black, Silver
Country of origin	China
Languages support	DEU, DUT, ENG, ESP, FRE, ITA, NOR
Number of cameras	1
Maximum frame rate	60 fps
Power cable length	4 m
Collision detection	No
Aperture range (F-F)	1.6 - 1.6
Main camera resolution	1920 x 1080 pixels
Main camera viewing angle	140 °
Video compression formats	MP4
Main camera sensor resolution	2.12 MP
Battery life	15 min
Battery weight	6 g
Output current	2 A
Output voltage	3.7 V
Battery capacity	320 mAh
Operating voltage	12 V
Power source type	Battery, Cigar lighter
Input operation voltage (max)	24 V
Storage temperature (T-T)	-20 - 45 °C
Display diagonal	2.5 \
Display resolution (numeric)	311 pixels
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Quantity per pack	7 pc(s)
Accessories included	Vdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Package type	Box
Package width	85 mm
Package height	45 mm
Package weight	410 g
Quantity per pallet	720 pc(s)
Master (outer) case width	280 mm
Master (outer) case height	370 mm
Master (outer) case length	330 mm
Master (outer) case weight	1025 g
Customs product code (TARIC)	8525890000
Master (outer) case GTIN (EAN/UPC)	5060384255675
Export Control Classification Number (ECCN)	EAR99
Number of shipping (inner) cases per master (outer) case	20 pc(s)

Weight and Dimensions

Depth	47 mm
Width	82 mm
Height	46 mm
Weight	82 g
