JAN 2024 Page | 20
5.5 Satellite Navigation
Dedicated multi-band and multi-
channel GNSS Receiver supporting
GPS, Galileo (L1, L5)
Reports (Update Rate 1Hz) NMEA, TAIP (PPS)
Reliable Store and Forward via serial UDP
5.6 Environmental
Operating Temperature (°F (°C)) -30 to +65 (-22 to +149)
Storage Temperature (°F (°C)) -40 to +90 (-40 to +194)
Operating humidity (non-condensing) 0 to 95%
Road vehicles - electrical test ISO-7637-2
Ingress Protection IP-54
Material flammability UL94
5.7 Power (Fixed and Mobile)
Input/Operating Voltage 9 to 36 VDC
Power modes
ON 18W Typical (1.5A @12V); Standby
120mW (10mA@12V)
Built-in protection against
voltage transients including
VDC engine cranking
Ignition Sense with time delay
shutdown
