5
Fig. 1 – VT-2200
External mounting tabs are provided that allow VT-2200 to be secured
to the chassis of the vehicle. If you are replacing a Wahoo 2, VT-2200
will fit in the area you have the Wahoo 2 secured. Additional
equipment is required to properly mount the VT-2200 hardware and is
provided in the installation kit for each VT-2200.
The VT-2200 connector configuration is composed of dissimilar
connectors to eliminate the chance of an installer incorrectly wiring
the unit. Five connectors make up the VT-2200’s configuration. The
connectors are power, GPIO, a serial port interface, GSM antenna
connector and GPS antenna connector.
1
Positive Edge
Signal
Green
2
Negative Edge
Signal 1
Yellow
3
Negative Edge
Signal 2
Blue
4
Output 1 Orange/White
