Nexus NX2 Compass - Clear; Calibration; Lighting

COMPASS English
5-15
4.2.5 Clear
A press on CLEAR, clear digits in edit mode.
4.2.6 Calibration
To access calibration mode, press and hold SET more than 2
seconds.
To return to main function mode, press SET when the text return
[RET] is displayed.
4.2.7 Lighting
The instrument uses red back lighting for both the display and the 5
push-buttons. The light can be set at 4 different levels.
To access the light control, press and hold PAGE for more than 2
seconds. The flashing text [Lit OFF] will be displayed and the
display will be lit momentarily.
To select between the 4 light levels, press UP: [LOW], [MED],
[MAX] and [OFF]. To lock the selected level, press SET.
The selected light level will be copied to all NX2 instruments
connected to the system. When the lighting is on, it is not possible
to reduce or turn off the light individually.
2 sec
2 sec
