1 Part specifications
NX2 Compass Data is delivered with all parts for mounting. Check prior to installation.
Compass Data instrument
Qty.
Description Reference
1 Instrument, NX2 Compass Data 1
1 Instrument front cover 2
1 Drill template 3
1 Installation and user manual 4
1 Warranty card 5
2 Pin bolts for instrument mounting 6
2 Nuts for instrument mounting 6
1 Tube of silicon grease 6
1 Connection cover 6
2 4-pol screw terminal 6
1 Power cable, red and black, 3 m (9 ft) 7
5 Extra wire protectors, 0,25 mm (1/100”) 8
5 Extra wire protectors, 0,75 mm (1/32”) 8
Additional items with Compass Data Instrument complete with
transducer
1 Compass transducer NX2 9
4 Mounting screws for Compass 10
Registering of this product
Once you have checked that you have all the listed parts, please take time to fill in the
warranty document and return it to your national distributor.
By returning the warranty card, it will assist your distributor to give you prompt and
expert attention, in the event of your experiencing difficulties with this product. Keep
your proof of purchase. Also, your details are added to our customer database so that
you automatically receive new product catalogues when they are released.
