Nexus NX2 Compass - 4.3 Main function; 4.4 Analogue function

English COMPASS
5-16
4.3 Main function
Top data is COMPASS HEADING.
Top data is either magnetic or true HEADING and your choice is set
in the set-up. When magnetic Compass course is selected, the small
MAG sign is lit on the LCD.
4.4 Analogue function
Press the PAGE button to change from Compass heading to steer
reference. The LCD arrow will then point at the text STEER instead
of HEADING.
HDC 360° The text HDC 360° means true or magnetic course for
the.
LCD pointer in a 360° scale
STR 60° The text STR 60° means that the course deviation is
amplified 3 times and displayed in a 60° scale.
At 360° scale, each sector represent 5° and at 60°scale each sector
represent 1
2
/
3
°.
Three sectors in steer mode
represents 2° error
Each sector in Compass mode
represents 5°
