4.2 Sweep
WF1943B 4-23
(4) Set the START frequency (START)
① Use the
and keys to produce the following display (START flashes).
１０００．００００００００ Ｈｚ
Ｆ－ＳＷＰ：ＴＹＰＥ ＭＯＤＥ ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ
4
② Press the
ENTER
key.
③ Set the start frequency with the key pad or
MODIFY
dial.
For example, set to 100 Hz.
④ After setting, press the
EXIT
key once to release the start setting mode.
(5) Set the STOP frequency (STOP)
① Use the
and keys to produce the following display (STOP flashes).
１０００．００００００００ Ｈｚ
Ｆ－ＳＷＰ：
3
ＳＴＯＰ ＴＩＭＥ ＣＥＮＴＥＲ ＳＰＡＮ
4
② Press the
ENTER
key.
③ Set the stop frequency with the key pad or
MODIFY
dial.
For example, set to 1000 Hz.
④ After setting, press the
EXIT
key once to release the stop setting mode.
(6) Set the sweep TIME
① Use the
and keys to produce the following display (TIME flashes).
１．０００ ｓ
Ｆ－ＳＷＰ：
3
ＳＴＯＰ ＴＩＭＥ ＣＥＮＴＥＲ ＳＰＡＮ
4
② Press the
ENTER
key.
③ Set the sweep time with the key pad or
MODIFY
dial.
For example, set to 2 seconds.
④ After setting, press the
EXIT
key once to release the sweep time setting mode.
