© National Instruments Corp. 11 NI 9795 User Guide and Specifications
Device Interface
Figure 4 shows the NI 9795 device interface.
Figure 4. NI 9795 Device Interface
1 Antenna RP-SMA Connector 2 Status LED
NI 9795
Status
WSN
Gateway
1
2
