NI PCIe-6353 - User Manual

Questions and Answers

M
michaelsimpsonAug 10, 2025
Why am I seeing crosstalk when sampling multiple NI PCIe-6353 I/O Systems channels?
- J
  jessica75Aug 10, 2025
  Crosstalk or ghost voltages when sampling multiple channels on NI I/O Systems can occur due to charge injection. To resolve this, use a voltage follower with operational amplifiers (op-amps) with unity gain for each high-impedance source before connecting to an X Series device. Alternatively, decrease the sample rate for each channel. If you are sampling among multiple channels at various gains, refer to the Multichannel Scanning Considerations section of Chapter 4, Analog Input.
S
stephanie21Aug 20, 2025
What to do if NI PCIe-6353 readings are random in differential analog input ground-reference mode?
- K
  Kelly GriffinAug 20, 2025
  If you observe random readings with rapid drift in differential analog input ground-reference mode on your NI I/O Systems device, check the ground-reference connections. Also, ensure that the signal is referenced to the same ground level as the device reference.
C
Christopher SmithAug 29, 2025
How to fix glitches on the output signal of NI PCIe-6353?
- S
  Sarah LoveAug 29, 2025
  Glitches on the output signal of NI I/O Systems can occur when a DAC switches from one voltage to another. To mitigate this, build a lowpass deglitching filter to remove some of these glitches.

Summary

Chapter 1: Getting Started

Safety and Compliance

Essential safety precautions and electromagnetic compatibility guidelines for device operation.

Installation and Setup

Steps for installing software, hardware, unpacking, and configuring USB devices like grounding and mounting.

Device Self-Calibration

Instructions for calibrating the X Series device for optimal accuracy.

Chapter 2: DAQ System Overview

DAQ Hardware and Architecture

Overview of DAQ hardware functions, components, and calibration circuitry.

Chapter 3: Connector and LED Information

I;O Connector Signal Descriptions

Detailed descriptions of signals found on the I/O connectors of X Series devices.

Chapter 4: Analog Input

MIO X Series Analog Input

Covers analog input circuitry, configuration, acquisition methods, triggering, and timing signals for MIO X Series devices.

Simultaneous MIO X Series Analog Input

Covers circuitry, configuration, acquisition methods, triggering, and signal connections for Simultaneous MIO X Series devices.

Chapter 5: Analog Output

Analog Output Overview

Overview of AO circuitry, DACs, FIFO, Sample Clock, and Reference Select signals.

Analog Output Triggering and Connections

Overview of trigger actions and methods for connecting AO signals.

Analog Output Timing Signals

Chapter 6: Digital I;O

Digital I;O Overview and Methods

Digital Input Operations

Digital Output Operations

Chapter 7: Counters

Counter Overview and Timing

Counter Input Applications

Counter Output Applications

Counter Timing Signals and Triggering

Chapter 8: PFI

PFI Overview and Configuration

Using PFI Terminals

I;O Protection and Power-Up States

Guidelines to avoid fault conditions and setting default states for PFI and DIO lines.

Chapter 9: Digital Routing and Clock Generation

Digital Routing and Clock Sources

Synchronizing Multiple Devices

PXI and PXI Express Clock and Trigger Signals

Chapter 11: Triggering

Triggering Overview

Digital Triggering

Analog Triggering

NI PCIe-6353 Specifications

General

Product Name	NI PCIe-6353
Category	I/O Systems
Form Factor	PCI Express
Interface	PCIe
Analog Input Resolution	16 bits
Analog Output Channels	4
Analog Output Resolution	16 bits
Output Range	±10 V
Digital I/O Channels	48
Counter/Timers	4
Analog Input Sample Rate	1.25 MS/s
Input Range	±10 V
Analog Output Sample Rate	2.86 MS/s
Operating Temperature Range	0 °C to 50 °C
Storage Temperature Range	-40 °C to 70 °C
Relative Humidity Range	10% to 90%, noncondensing
