Nibe F1245 Series User Manual

F1245-12F1245-10F1245-8F1245-6Model
126111105100kgWeight only cooling module
Lead in brass componentsSubstances according to Directive (EG) no. 1907/2006, article 33 (Reach)
- / 065 313 /
065 108
- / 065 589 /
065 553
- / 065 588 /
065 552
- / 065 587 /
065 551
Part number, 3x400 V, with energy meter (Cu / Rf / E)
4
065 078 /
065 083 /
065 087
065 541 /
065 544 /
065 547
065 540 /
065 543 /
065 546
065 539 /
065 542 /
065 545
Part number, 3x400 V (Cu / Rf / E)
4
1
Scale for the product’s efficiency class room heating: A+++ to D.
2
Scale for the system’s efficiency class room heating: A+++ to G. Reported efficiency for the system takes the product’s temperature
regulator into account.
3
Scale for efficiency class hot water: A+ to F.
4
Cu: copper, Rf: stainless steel, E: enamel.
5
With feet removed, the height is approx. 1,930 mm.
WORKING RANGE HEAT PUMP,
COMPRESSOR OPERATION
The compressor provides a supply temperature up to
65 °C at 0 °C incoming brine temperature.
6 - 10 kW 3x400V
0
-10 -5 0 5 10 15 20 25 30 35
10
20
30
40
50
60
70
Text text bla bla
(enhet)
Temperature, °C
Flow pipe
Return pipe
Incoming brine temp, °C
12 kW 3x400V
0
-15 -10 -5 0 5 10 15 20 25 35
20
40
60
70
Vattentemperatur
(°C)
Köldbärare in
(°C)
30
Framledning
Returledning
50
30
10
Temperature, °C
Flow pipe
Return pipe
Incoming brine temp, °C
NIBE F1245Chapter 12 | Technical data74
