SERVICE INSTRUCTIONS
NIBE F1245/F1255
General
When replacing the heater in F1245/F1255 the cooling
module, pipe connections, insulation and all electrical
equipment are transferred from the existing heat pump
to the heater with stand.
NOTE
Servicing should only be carried out by persons with
the necessary expertise.
When replacing components on NIBE F1245/F1255
only replacement parts from NIBE may be used.
Contents (kit list)
DescriptionQuantityPart no.
Cable tie for insulation for Brine valves
(QM33) and (QM34)
8x016940
Heat conducting paste for (BT6) and
(BT7)
2x021081
Securing plate for valves (QM31, 32, 33
, 34)
4x028028
Gasket shut-off valve immersion heater
(QM31)
1x033658
Stand mountings electrical cabinets4x037312
Gasket kit with 8 x O-rings for (QM31,
32, 33, 34)
1x059392
Insulation tape 300x50x3, for insulation
of Brine valves (QM32, 33)
1x425728
Angle connector for connection to HW
charge coil
2x524210
13NIBE F1245/F1255
GB

Nibe F1245 Specifications

General

Refrigerant	R410A
Control System	NIBE SMO 40
Dimensions (HxWxD)	1800 x 600 x 620 mm
Energy Efficiency Class Heating 35°C	A++
Energy Efficiency Class Heating 55°C	A++
Heating Capacity	5-12 kW
COP Heating	4.5
Integrated Hot Water Tank	180 liters
Power Input Heating	1.0 - 3.0 kW
