List of components
Miniature circuit-breaker2
Service connection, low pressure7
Terminal block, incoming supply9
Terminal block, charge pump, common alarm11
Terminal block, additional, downtime14
Temperature sensor, outdoor air15
Evaporator17
Condenser18
4-way valve19
Drip tray heater24
Compressor heater25
Motor protection, including reset26
Compressor27
Relay card with power supply unit29
Terminal block, thermostat30
High pressure pressostat33
Control card with display34
Fan36
Plus button37
Minus button38
Enter button39
Reset button40
Low pressure pressostat41
Service connection, high pressure42
Display contrast43
Connection, communications44
Expansion valve48
Operating condenser, fan57
Suppressor60
Particle filter (supplied)63
Drying filter65
Non-return valve66
Contactor, compressor68
Connection, heating medium out of F2025, G1 (Ø28 mm)70
Connection, heating medium in to F2025, G1 (Ø28 mm)71
Temperature sensor, evaporator86
Temperature sensor, fluid pipe88
Temperature sensor, flow pipe89
Temperature sensor, suction gas90
Temperature sensor, hot gas91
Temperature sensor, return93
Type plate95
Soft-start relay97
Cable gland, incoming supply100
Cable gland, sensor102
Serial number103
Connections sensors104
F202542
Miscellaneous
Technical specifications
