Nibe F2120 Series User Manual

Compatible indoor modules (VVM) and control
modules (SMO)
SMO 40SMO 20VVM 500VVM 320VVM 310
XXXXXF2120-8
XXXXXF2120-12
XXXXXF2120-16
XXXXXF2120-20
Indoor modules
VVM 310VVM 310
With integrated EMK 310
Part no. 069 084
Part no. 069 430
VVM 320
Stainless steel, 3x230 V
Part no. 069 113
VVM 320
Stainless steel, 1x230 V
Part no. 069 111
VVM 320
Stainless steel, 3x400 V
Part no. 069 109
VVM 320
Enamel, 3x400 V
With integrated EMK 300
Part no. 069 110
VVM 500
Part no. 069 400
VVM 320
Copper, 3x400 V
Part no. 069 108
Control modules
SMO 20
Control module
Part no. 067 224
SMO 40
Control module
Part no. 067 225
NIBE F2120Chapter 1 | Important information8

Nibe F2120 Series Specifications

General

Type	Air/Water Heat Pump
Operating Temperature Range	-25°C to +45°C
Refrigerant	R410A
Max. Flow Temperature	65°C
Heating Capacity	8-20 kW
Power Supply	3-phase, 400V
SCOP	5.0 (Model dependent, refers to average climate, low temperature application)
