Dimensions, two-way valve
42
37
ISO 228/1-G1
(2x)
74
6,4 ± 0,1
Dimensions, three-way valve
36,5
42
37
ISO 228/1-G1 (3x)
74
6,4 ± 0,1
Dimension actuator
Two-way valve
5
7
,
5
5
8
44,6
2
9
108,8
Three-way valve
5
7
,
5
108,8
44,6
2
9
5
8
NIBE SPLIT ACVM270Chapter 4 | Component description26
