Technical specifications, actuators from 2014 until further notice
Valves
Three-way valveTwo-way valveType
G1” extG1” extConnection
74 mm74 mmLength
4.58.6KVS value
Actuator
First EMV-110 9F70-M (Three-way)First EMV-110 9GN0-M (Two-way)Type
AC 100-240 VAC 100-240 VVoltage
50/60 Hz50/60 HzFrequency
5 W11 WOutput
3 x 0.75 mm
2
3 x 0.75 mm
2
Electrical connections
40 s / 90 °12 s / 90 °Run time
27Chapter 4 | Component descriptionNIBE SPLIT ACVM270
