Dimensions, two-way valve
44
74
42
1”
Dimensions, three-way valve
44
74
42
1”
39
Technical specifications, 2009 - 2014
Valves
V515B (Three-
way)
V415B (Two-
way)
Type
G1” extG1” extConnection
74 mm74 mmLength
4.58.6KVS value
Actuator
LR230A-002 LI LinegType
AC 100-240 VVoltage
50/60 HzFrequency
1.5 WOutput
3 x 0.75 mm
2
Electrical connections
35 s / 90 °Run time
Dimension actuator
25
103
84
134
71
R65
1 2 3
6
0
0
1
0
3
2
5
1
3
4
71
