Component positions
VPB 1000VPB 750VPB 500
XR1
UL1
PF3
BT7
UA1
UA2
QQ1
XR1
UL1
PF3
BT7
UA1
UA2
NameDesignation
Hot water sensor, top (factory fitted)BT7
Inspection hatchQQ1
Submerged tube, docking, Ø 11 mm (int)UA1
Submerged tube, solar, Ø 11 mm (int)UA2
Adjustable feetUL1
Lifting eyeXR1
Serial number platePF3
NIBE VPB | GB20
