Installation
NIBE VPB can be equipped with the following elements,
connection dimension G50. When installing the water
heater, ensure that there is enough room in front of the
connection area to remove the element, see following
table.
Fit the enclosed cover discs before pipe installation. The
cover discs, with self-adhesive backs, must be installed
on the relevant connection, by pushing them over the
connections.
All connections (including connections or holes left by
the lifting eyes that are not used) must be insulated to
minimise energy losses.
Immersion heaters
Free spaceOutputElement
250 mm1500 WIU 31
260 mm2250 WIU 33
280 mm3000 WIU 34
400 mm4500 WIU 36
400 mm6000 WIU 39
400 mm7500 WIU 310
400 mm9000 WIU 311
NIBE VPB | GB22
