14 - BOARD NOMENCLATURE
Adjust force settings
for gate opening and
closing
Adjust speed settings
for gate opening and
closing
Gate delay time
select
Function select Display select
Spare fuses
Incoming
30 Amp fuse
Reset and hard
shut down
button
LCD screen
Ok or accept
Selection down
Selection up
Open the gate
Stop gate
movement
Close the gate
