CAUTIONS: • The technical features set out refer to an ambient temperature of 20°C (± 5°C). • Nice S.p.a. reserves the right to make alterations to the product
any time it deems it necessary, keeping the same functionality and destination of use.
WG4024 WG5024
Type
electromechanical gear motor for gates or doors with leaf opening
Power input 24 V
24 V
Maximum absorption 3,5 A 3,5 A
Nominal absorption 2 A 2 A
Maximum absorbed power 85 W 85 W
Nominal absorbed power 50 W 50 W
Protection grade IP 44 IP 44
Travel 320 mm 470 mm
Speed loadless 0,018 m/s 0,016 m/s
Maximum thrust 1500 N 1500 N
Nominal thrust 500 N 500 N
Operating temperature
Cycles h at nominal torque 40 40
Durability
estimated between 80,000 and 250,000 cycles of manoeuvres according to the conditions set out in Table 2
Insulation class A A
Dimensions (mm) 770 x 98 x 95 h 920 x 98 x 95 h
Weight (kg)
6 7
TECHNICAL FEATURES OF THE PRODUCT
2
WG4024
98 mm
770 mm
320 mm
WG5024
98 mm
920 mm
470 mm
95 mm
95
mm
