STANDBY MODE puts the board into a “Low Power Consumption
Standby Mode”. Press any button to “wake” the board. Select ON
or OFF as follows:
1. Press FUNCTIONbutton.
2. Scroll to "Standby" menu (8th menu).
3. Press OK.
4. Use UP and DOWN buttons to select desired amount of time
before system enters "Standby Mode". 20-30 seconds is the
recommended setting.
5. Press OK.
6. Once this is done, the operator will enter a Standby Mode after the set time when the operator is
not moving, it is either in the auto-close countdown or is being held open by an external auxiliary
input.
SELECT CONTROL BOARD STANDBY MODE
13
NOTICE
’ When display is OFF In
Standby Mode only a
“heartbeat” will be present
at the OK LED.
’ Voltage at terminal #20
(24VDC) and terminal
#38 (12VDC) will turn o -
do not power entry or exit
devices from this output.
’ BlueBUS function is
disabled until board
“wakes” up. Press any
button to wake.
IMPORTANT!
For SOLAR APPLICATIONS - Turn the Standby Mode ON.
