FUNCTION>CHARGER MENU:
Built-in battery charger is for use with backup battery. Charger may be manually programmed for customized
charge settings or set to “Auto” for battery charging profile that automatically compensates for temperature
and current during charging.
FUNCTION
7. Charger
Charger
O
O
On
8. Standby
(see below)
6. Events (see previous page)
OK
OK
FUNCTION
8. Standby
Standby
30s
30 sec.
OFF
9. Adv. Sengs
(see next page)
7. Charger (see above)
FUNCTION>STANDBY MENU:
Programs timeout of low power standby mode for gate operator. The Standby setting may be set to either
30 seconds or OFF. During low power standby there is no data displayed on the gate operator LCD and it
consumes a minimum amount of power to extend the life of the backup battery. Most of the outputs, including
output power at #20 (24v) and #38 (12V), are switched o during Standby Mode and the OK LED blinks to
indicate standby status. Output #11 (V+) provides power during Standby Mode.
OK
OK
FUNCTION Button / Charger
FUNCTION Button / Standby
NOTICE
30 seconds is the
recommended setting.
