Nice FLOX2R

ADJUSTMENTS AND SETTINGS
Selection of the relays on the channels
Each receiver can recognise all 4 transmitter channels (channels = keys). Association of the output
relays to the channel required is done via a jumper that has to be plugged in.
SELECTION OF 1
ST
RELAY SELECTION OF 2
ND
RELAY (if present)
Fig. 6
CHANNEL 1
CHANNEL 2
CHANNEL 3
CHANNEL 4
CHANNEL 1
CHANNEL 2
CHANNEL 3
CHANNEL 4
