IDENTIFICATION - CONNECTORS
AND CABLES
IDENTIFICATION - KEYS AND JUMPERS
4
5
(+) Auxiliary output “positive” for accessories.
(-)
Auxiliary output “negative” for accessories
(GND contact).
S1 Zone 1 input for wire sensors.
Led
12V/100mA auxiliary output that is
activated whenever the fence is turned on.
Indicates activated system.
SIR Positive from the siren.
NA
NA Contact (normally open) from the
auxiliary relay.
CM
CM Contact (common) from the auxiliary
relay.
NF
NF Contact (normally closed) from the
auxiliary relay.
Red cable Positive (+) from the battery.
Black cable Negative (-) from the batter.
JZ Jumper Enables the wired sensor input at Zone 1.
TEMPO DE SIRENE
Jumper
Used for timing the siren to 15 seconds, 2
or 5 minutes.
JP Jumper
It should be OPEN to enable the cutting
alarm and wire grounding. If this
jumper is closed the siren will not trigger in
case of a violation of the fence wires.
AJUSTE DE
SENSIBILIDADE
Jumper
Congures the sensibility of high voltage
pulse returns.
