CONNECTION - POWER GRID
6
220 Vac Power Grid
Use “N” and “220” connectors
Command board
High voltage board
Power grid
Power grid
127 Vac Power Grid
Use “N” and “127” connectors
Command board
High voltage board
Always attempt to connect the power grid’s neutral to the board’s neutral
(N) to increase the equipment protection.
