No. Command Description
It causes a closure manoeuvre, after which the automation
is blocked; the control unit accepts no further commands
with the exception of “Step by step high priority”, “Release”
automation and (from Oview only ) the commands “Release
and close” and “Release and open”
It causes the manoeuvre to stop and the automation to
block; the control unit accepts no further commands with
the exception of “Step by step high priority”, “Release” au -
to mation and (from Oview only ) the commands “Release
and close” and “Release and open”.
It causes the automation to be released and normal opera-
tion to resume
The Courtesy light comes on with timed turning off
The Courtesy light turns on and off in step-by-step mode
11 Close and block
automation
12 Block automation
13 Release
automation
14 Courtesy light
timer on
15 Courtesy light
on-off
following the relevant warnings) and can remain connected to the control unit
during normal operation of the automation. In this case a specific “user” menu
enables commands to be sent directly to the control unit. It is also possible to
update the firmware. If an OXI family radio receiver is present in the control unit,
Oview enables access to the parameters of the transmitters memorised in this
receiver.
Further information is available in the instruction manual and the “Opera system
book” manual.
7.3 - Connecting the Solemyo solar energy system
To connect the solar energy system see fig. 10.
IMPORTANT! – When the automation is powered by the “Solemyo” sys-
tem, it MUST NOT BE POWERED at the same time from the electrical
mains.
For other information, refer to the relevant instruction manual.
7.4 - Connecting model PS324 buffer battery
To connect the buffer battery, see fig. 10. For other information, refer to the rel-
evant instruction manual.
7.2 - Connecting Oview programming unit
Connector BusT4 on the control unit enables connection of the programming
unit Oview which enables complete and rapid management of installation,
maintenance and troubleshooting of any malfunctions of the whole automation
system. To gain access to the connector, proceed as shown in fig. 9 and con-
nect the connector to its seat. The Oview can be connected simultaneously to
a number of control units (up to 5 without any particular precautions, up to 60
PRODUCT MAINTENANCE
8
Regular maintenance is needed to keep the level of safety constant and to
ensure the maximum durability of the entire automation.
Maintenance must be performed in strict accordance with the safety provisions
set out in this manual and with the requirements of applicable laws and stan-
dards.
Important – During maintenance and cleaning the control unit must be discon-
nected from the electrical power supply.
For devices other than the MC824H follow the instructions given in the relevant
maintenance programmes.
For the MC824H scheduled maintenance must be performed no more than 6
months or 20,000 manoeuvres after previous maintenance.
To perform maintenance, proceed as follows:
01. Disconnect all electric power sources, including any buffer batteries;
02. Check all materials making up the control unit for wear, with particular
attention to erosion or oxidation of parts; replace parts that are not in opti-
mal condition;
03. Reconnect the power supply and perform the checks described in chapter
4.1 - Testing.
PRODUCT DISPOSAL
This product is an integral part of the automation system it controls and
must be disposed of along with it.
As in the case of installation, likewise at the end of product lifetime the disas-
sembly and scrapping operations must be performed by qualified personnel.
This product is made of various types of material, some of which can be recycled
while others must be scrapped. Seek information on the recycling and disposal
methods envisaged by the local regulations in your area for this product category.
Important! – Some parts of the product may contain polluting or hazardous
substances which, if released to the environment, may cause serious damage
to the environment or to human health.
As indicated by the symbol alongside, disposal of this product
with domestic waste is strictly prohibited. Separate the waste into
categories for disposal, according to the methods established by
current legislation in your area, or return the product to the retailer
when purchasing a new version.
Important! – Local legislation may impose heavy fines in the
event of illegal disposal of this product.
Disposal of buffer battery (if present)
Important! – Even if discharged, the batteries may contain pollutant sub-
stances and therefore must NEVER be disposed of in normal waste collection
points.
Dispose of according to separate waste collection methods as envisaged by
current local standards.
