WARNINGS: • All technical characteristics stated refer to an ambient temperature of 20°C (±5°C). • Nice S.p.a reserves the right to modify the product at any time while maintaining the
same functionalities and intended use.
MC824H power supply 230 Vac (+10% -15%) 50/60 Hz
MC824H/V1 power supply 120 Vac (+10% -15%) 50/60 Hz
Nominal power absorbed from mains 200 W
Power absorbed from mains in
2 W
“standby - All” operation (including a receiver)
Power absorbed by control unit battery
connector with “standby-All” operation below 100 mW
(including a receiver with SM type connector)
Flashing light output [*] 1 “LUCYB” type flashing light (12 V, 21 W lamp)
Electric lock output [*] 1 max. 12 Vac max. 15 VA electric lock
Gate open light output [*] one 24 V max. 4 W lamp (output voltage may vary between -30% and +50%, output may also control small relays)
BLUEBUS output
1 output with maximum load 15 Bluebus units (maximum 6 pairs of MOFB or MOFOB photocells + 2 pairs of MOFB or MOFOB
photocells assigned as Opening devices + max. 4 MOMB or MOTB control devices
STOP Input
For normally closed, normally open or 8.2 kΩ constant resistance contacts in self-learning mode (a change from the memorised
state prompts the “STOP” command)
PP Input for normally open contacts (closure of the contact prompts the Step by Step command)
OPEN Input for normally open contacts (closure of the contact prompts the OPEN command)
CLOSE Input for normally open contacts (closure of the contact prompts the CLOSE command)
Radio connector SM connector for SMXI, OXI and OXIFM family receivers
Radio AERIAL input 50 Ω for RG58 or similar type cable
Programmable functions 8 ON-OFF type functions and 8 adjustable functions
• Self-learning of devices connected to the BlueBus output
Functions in self-learning mode • Self-learning of type of device connected to “STOP” terminal (NO, NC or 8.2 kΩ resistance contact)
• Self-learning of leaf travel and automatic calculation of deceleration and partial opening points (vary according to installation)
Operating temperature from - 20 °C a + 50 °C
Use in particularly acid, saline or
NO
potentially explosive atmospheres
Protection rating IP 54 with enclosure intact
Dimensions (mm) 310 x 232 x H 122
Weight (kg) 4,1
[*] The Flashing Light, Electric Lock and Gate Open Warning light outputs can be programmed with other functions (see “TABLE 5 - 1st level functions”; or via Oview programmer, see
chapter 7.2). The electrical characteristics of the output vary according to programming:
flashing light: 12Vdc, 21 Wmax lamp
electric lock: 12Vac 15 VAmax
other outputs (all types): 1 lamp or relay 24Vdc (-30 and +50%), 4 Wmax
TECHNICAL CHARACTERISTICS OF THE PRODUCT
CE DECLARATION OF CONFORMITY
Note - The contents of this declaration correspond to declarations in the last revision of the official document deposited at the registered offices of Nice Spa available before this manual was printed. The text herein has been re-edited for editorial pur-
poses.
Number: 298/MC824H Revision: 1
The undersigned, Luigi Paro, in the role of Managing Director, declares under his sole responsibility, that the product:
Manufacturer’s Name: NICE s.p.a.
Address: Via Pezza Alta 13, Z.I. Rustignè, 31046 Oderzo (TV) Italy
Type: two 24 Vdc motor control unit
Models: MC824H
Accessories: Radio receiver SMXI, OXI, OXIFM, PS 324, SYKCE, OVIEW unit
Conform with the requirements of the following EC directives:
• 98/37/EC (89/392/EEC amended); DIRECTIVE 98/37/EC OF THE EUROPEAN PARLIAMENT AND COUNCIL of 22 June 1998 regarding the approximation of member state legislation relating
to machinery.
As established in directive 98/37/EC, the above-mentioned product may not be started up unless the machine in which the product is incorporated has been identified and declared as con-
forming to directive 98/37/EC.
The product also complies with the requirements of the following EC directives:
• 2006/95/EEC (ex directive 73/23/EEC); DIRECTIVE 2006/95/EEC OF THE EUROPEAN PARLIAMENT AND COUNCIL of 12 December 2006 regarding the approximation of member state leg-
islation relating to electrical material intended for use within specific voltage limits
According to the following harmonised standards: EN 60335-1:1994+A11:1995+A1:1996+A12:1996+A13:1998+A14:1998+A15:2000+A2:2000+A16:2001
• 2004/108/EEC (ex directive 89/336/EEC); DIRECTIVE 2004/108/EEC OF THE EUROPEAN PARLIAMENT AND COUNCIL of 15 December 2004 regarding the approximation of member state
legislation relating to electromagnetic compatibility, repealing directive 89/336/EEC
According to the following harmonised standards: EN 61000-6-2:2005; EN 61000-6-3:2007.
The product also complies, within the constraints of applicable parts, with the following standards: EN 60335-1:2002+A1:2004+A11:2004+A12:2006+ A2:2006, EN 60335-2-103:2003, EN
13241-1:2003; EN 12453:2002; EN 12445:2002; EN 12978:2003
Oderzo, 11 June 2009
Luigi Paro (Managing Director)
